Potato storage ventilator - Energy recovery Ventilator

Potato storage ventilator - Energy recovery Ventilator

250000 INR/Number

Get a Price/Quote

Product Details:

Usage Energy Recovery Ventilator for Potato storgae
Weight 500 Kilograms (kg)
Width 1400 Millimeter (mm)
Height 1800 Millimeter (mm)
Length 3400 Millimeter (mm)
Product Type Energy Recovery Ventilator for Potato storgae
Size 3400CFM
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Potato storage ventilator - Energy recovery Ventilator Price And Quantity

Price 250000 INR/Number
Minimum Order Quantity 1 Number

Potato storage ventilator - Energy recovery Ventilator Product Specifications

Type Commercial
Usage Energy Recovery Ventilator for Potato storgae
Weight 500 Kilograms (kg)
Capacity 5780 m3/hr
Width 1400 Millimeter (mm)
Height 1800 Millimeter (mm)
Voltage 415 Volt (v)
Installation Type Other
Length 3400 Millimeter (mm)
Product Type Energy Recovery Ventilator for Potato storgae
Power 4500 Watt (w)
Size 3400CFM
Function Ventilation
Color White
Material Aluminum

Potato storage ventilator - Energy recovery Ventilator Trade Information

FOB Port ICD Bangalore
Payment Terms Cash Advance (CA), Cash in Advance (CID), Cheque, Letter of Credit at Sight (Sight L/C), Western Union, Letter of Credit (L/C)
Supply Ability 50 Number Per Month
Delivery Time 4 Week
Sample Available Yes
Sample Policy Contact us for information regarding our sample policy
Packaging Details Wooden packing
Main Export Market(s) Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market All India

Product Description

Highly efficient heat recovery units up to 80% with rotary wheel, forward curved /backward curved blades/direct driven/belt driven. Pre-configured control system for easy start-up. The casing is made of 25 mm, self-supporting Double skinned panels. The outer skin is made from coated steel with a high resistance against corrosion and UV light and the inner skin is made from galvanised steel. Support feet are made from GI. Easy access to all components via large, hinged front doors. Square inlet and discharge connection flanges.

Unit made Aluminium profile & Corner Joints

Inside sheet made of 0.5mm thickness GI

Outside sheet made of 0.5mm thickness pre-painted GI

25mm thickness Polyurethane foam with 48kg/m3 density

Fasteners are made of Stainless Steel 304.

200mm thick AirCoil Rotor.

High heat recovery performances.

Less space requirements.

Less self-consumed energy.

Low pressure drops.

Power for rotor drive is negligible.

Forward / Backward Curved blowers on Supply & Return Side.

Inbuilt Control panel (Optional)

25mm Thick G4 Filters on Supply & Return Side.

Complete unit mounted on 70/100mm Base Frame made of 1.5-2mm thickness GI

Wooden Pallet, Corrugated packing, Shrink Wrap shall be provided in packing.

Model Number:	ERV3400
Supply Air Flow Rate (CFM)	3400
Supply Air Total Static Pressure (Pa)	900
Return Air Rate (CFM)	3400
Return Air Total Static Pressure (Pa)	900
Rotor Size	HRE/1200/200/1.7
Energy Effectiveness	>70%
Controller	Electrical Starter panel with Remote Start /stop (Optional)
Working Temperature Range	-10 to +60C
Maximum Unit Power (KW)	7.52(3.7+3.7+0.12)
Sound Level	70DbA
Phase /Voltage/Hertz	3Ph/415V/50Hz
